Construction: Moulded carbon fibre and honeycomb composite structure that surpasses latest FIA impact and strength regulations
Front suspension: Wishbone & pushrod-activated torsion springs and rockers, mechanical anti-roll bar
Rear suspension: Wishbone & pushrod-activated torsion springs and rockers, mechanical anti-roll bar
Dampers: Showa
Wheels: BBS forged magnesium (front: 312mm wide, rear: 340mm wide)
Tyres: Michelin
Brakes: Alcon (2 x 6-piston calipers in front and back)
Brake discs/pads: Carbon/Carbon
Steering: B.A.R power assisted Rack & Pinion
Steering wheel: B.A.R carbon fibre construction
Driver’s seat: Anatomically formed carbon composite
Seat belts: Six-point harness (75mm shoulder straps with HANS system)
Fuel cell: ATL kevlar-reinforced rubber bladder
Fuel capacity: 150 litre
Battery: 3Ah Lead Acid
Instrumentation: B.A.R steering wheel dash display
Gearbox: B.A.R maincase: 7-speed unit, Honda & XTrac internals
Gear selection: Sequential, semi-automatic, hydraulic activation
Clutch: Carbon plate
Front track: 1460mm
Rear track: 1420mm
Wheel base: 3140mm
Overall length: 4675mm
Overall height: 950mm
Overall width: 1800mm
Designation: Honda RA005E
Configuration: 90° V10, naturally aspirated
Displacement: 3.0litres
Maximum power: Over 900bhp
Maximum revs: Over 18,500 rpm
Valve train: 4 valves per cylinder; pneumatic valve system
Injection system: Honda PGM-FI
Throttle system: Electronic hydraulically-operated system
Ignition system: Honda PGM-IG
