Chassis: Carbon-fibre monocoque, manufactured and designed in-house
Front suspension: Upper and lower carbon wishbones, inboard torsion springs and dampers actuated by push-rods
Rear suspension: Upper and lower carbon wishbones, inboard torsion springs and dampers mounted inside gearbox casing, actuated by pull-rods
Dampers: Undisclosed
Brakes: 6 piston front and 4 piston rear calipers with carbon discs and pads (calipers by Brembo, master cylinders by AP Racing)
Transmission: Lotus eight speed seamless sequential semi-automatic shift plus reverse gear, gear selection electro-hydraulically actuated, titanium casing
Clutch: Carbon fibre plates.
Electronics: FIA standard ECU and FIA homologated electronic and electrical system (as provided by MES)
Cooling system: Aluminium oil, water and gearbox radiators
Tyres: Pirelli
Wheels: OZ Racing, machined magnesium alloy
Fuel system: ATL Kevlar-reinforced rubber bladder
Length: Undisclosed
Height: 950 mm (minus T camera)
Track width: 1,600 mm (front); 1,550 mm (rear)
Weight: 728kg (FIA mininum; incl. driver and lubricants, tank empty)
Width: 2,000 mm (FIA maximum)
Designation: Renault R.E.17
Type: Turbocharged, 90° 1.6l V6, assisted with kinetic and heat ERS
Valves: 24 (4 per cylinder)
Rev limit: 15,000rpm
Pressure charging: Single turbocharger, unlimited boost pressure (typical maximum 3.5 bar abs due to fuel flow limit)
Bore: 80mm
Stroke: 53mm
Crank height: 90mm
Construction: Cylinder block in aluminium
Exhaust: Single exhaust outlet, from turbine on car centre line
Injection: Direct fuel injection, limited to 500bar
Weight: Undisclosed (at least 145kg)
Total horsepower: Approx 900bhp
Energy recovery system: Energy Recovery Systems incorporating two motor generator units – the MGU-H, recovering energy from the exhaust and the MGU-K recovering energy from braking
Energy Store: Battery solution (up to 4MJ per lap), between 20 and 25 kg
