Chassis: carbon-fibre monocoque
Suspension: upper and lower wishbones (front and rear),
inboard springs and dampers, actuated by pushrods (Sachs Race Engineering)
Brakes: six-piston brake callipers (Brembo), carbon pads and discs (Brembo, Carbone Industrie)
Transmission: G1.09 7-speed 'quick-shift' gearbox designed to last 4 races, longitudinally mounted, carbon-fibre clutch
KERS: System with energy storage in batteries, BMW Sauber F1 Team
Chassis electronics: MES
Steering wheel: BMW Sauber F1 Team
Tyres: Bridgestone Potenza
Wheels: OZ
Length: 4690 mm
Width: 1800 mm
Height: 1000 mm
Track width, front: 1470 mm
Track width, rear: 1410 mm
Weight: 605 kg (incl. driver, tank empty)
Type: BMW P86/8, normally aspirated V8
Bank angle: 90 degrees
Displacement: 2,400 cc
Valves: four per cylinder
Valve train: pneumatic
Engine block: aluminium
Cylinder head: aluminium
Crankshaft: steel
Oil system: dry sump lubrication
Engine management: standard ECU (MES)
Spark plugs: NGK
Pistons: aluminium
Connecting rods: titanium
Length: 518 mm
Width: 555 mm
Height: 595 mm (overall)
Weight: 95 kg
Maximum engine speed: 18000 rpm
